The Silent Design Series exhaust fans bring style and elegance to any contemporary bathroom, ensuite and toilet. They can be wall or ceiling mounted and feature an advanced vibration absorbing design that ensures quiet operation. Sizes to fit 100, 125 and 150mm duct are available and models with a run-on timer and humidistat are included in the range.

Features

• Quiet operation due to its noise and vibration absorbing design
• Ideal for modern homes and commercial application
• Suitable for wall and ceiling installations
• To complement room fixtures all models are available in white and silver finish - other colours also available.*
• Comes with 4 interchangeable colour bars to match room décor.
• Backdraft damper is standard on all models
• All models can be used to exhaust along a short length of duct. It is essential allowances be made for pressure losses in the duct to ensure air flows will meet the requirements of the application
• Class B motor, IP45 rated
• 'CZ' Range - Includes backdraft damper
• CRZ' Range - Includes backdraft damper and 1-30 minute adjustable run-on timer
• 'CHZ' Range - Includes backdraft damper, 1-30 minute adjustable run-on timer and adjustable humidistat
• Available in spigot diameter sizes to suit 100, 125 and 150mm duct.

* 12 week lead time applies

Construction
Manufactured from injection moulded plastic.
All units have weather and impact resistant housings.

Motors
Type - shaded-pole induction motor
Electricity supply - single-phase 230V, 50Hz.
Bearings - Ball.
Maximum ambient temperature - 40°C
Class II insulation, IP45 rated

Internal Thermal Protection
All 100 models - impedance
All 200 and 300 models - fuse

Testing
Air flow to ISO5801: 1997
Noise to ISO13347-3
